A 4 flute spiral end mill is the general purpose cutter for steel. Four flutes give a stronger core and a finer finish than a 2 flute, at the cost of chip room, which is why it suits side (peripheral) milling and light slotting rather than deep full-width slots. The TiSiN coating lets it run in carbon steel, alloy steel, stainless and pre-hardened material up to HRC55 without the edge burning off.
On a CNC router this is the cutter for steel brackets, jigs and fixtures where you need accurate walls and a square corner. For aluminium use a 2 or 3 flute uncoated or DLC end mill instead; the extra flutes on this tool will pack up with soft, gummy chips.
4 flute solid carbide slot mill with a TiSiN coating giving it a capability to cut materials up to HRC55. This mill is primarily used for edge or peripheral milling.
Sizes run from 1mm to 16mm cutting diameter on 4mm to 16mm shanks, with standard and extra-long cut lengths in the popular sizes.
Every size lists a starting feed rate on the product page where we have tested it. For the method behind the numbers read the Feeds & Speeds Guide, or use Message Adam above if you're unsure which size suits your machine.
Stocked in our Laverton North (Melbourne) warehouse and shipped Australia-wide. Standard shipping is free on orders over $200.
Sizes and dimensions
4 Flute SPIRAL Carbide End Mill TiSiN HRC 55 comes in 17 sizes. Pick yours from the size options above; the dimensions for each are listed here.
| Cutting diameter | Shank | Cut length | SKU |
|---|---|---|---|
| 1mm | 4mm | 4mm | 1-4-SP-4F-4-C55 |
| 1.5mm | 4mm | 4mm | 1.5-4-SP-4F-4-C55 |
| 2mm | 4mm | 6mm | 2-4-SP-4F-6-C55 |
| 3mm | 4mm | 8mm | 3-4-SP-4F-8-C55 |
| 4mm | 4mm | 11mm | 4-4-SP-4F-10-C55 |
| 4mm | 4mm | 20mm | 4-4-SP-4F-20-C55 |
| 5mm | 5mm | 35mm | 5-5-SP-4F-35-C55 |
| 6mm | 6mm | 15mm | 6-6-SP-4F-15-C55 |
| 6mm | 6mm | 40mm | 6-6-SP-4F-40-C55 |
| 8mm | 8mm | 20mm | 8-8-SP-4F-20-C55 |
| 8mm | 8mm | 40mm | 8-8-SP-4F-40-C55 |
| 10mm | 10mm | 25mm | 10-10-SP-4F-25-C55 |
| 10mm | 10mm | 35mm | 10-10-SP-4F-35-C55 |
| 10mm | 10mm | 50mm | 10-10-SP-4F-50-C55 |
| 12mm | 12mm | 30mm | 12-12-SP-4F-30-C55 |
| 14mm | 14mm | 45mm | 14-14-SP-4F-45-C55 |
| 16mm | 16mm | 45mm | 16-16-SP-4F-45-C55 |
Buying guide: 2 vs 3 vs 4 Flute End Mills
