2 Flute COMPRESSION Diamond Like Carbon DLC Carbide End Mill

$29.95
(3 reviews) Write a Review
SKU:
6-6-CM-2F-22-DLC [S4]
Adding to cart… The item has been added

If an up cut gives you a great bottom finish and a down cut a great top finish, why not have both with a compression cutter! A compression cutter starts with an up cut component usually the length of the diameter (e.g. ⅛” has a ⅛” up cut component and the rest to down cut) so get the full benefit of the cutter, your first plunge must go below that length (e.g. ⅛” or more). Compression cutters like to run a bit faster than other wood cutting bit to get the best finish along the side of your material.

Suitable for

  • Laminate
  • Melamine Particle Board
  • MDF/HDF
  • Veneered Plywood
  • Softwood

Not advisable

  • Hardwoods

Adam’s Tips

Albeit compression bits are primarily used for slot cutting, you can still profile cut as long as you go past the up cut component. This will give you both a perfect bottom and top finish.

Feeds and Speeds - 2 Flute Compression DLC
mm per minute

 Wood
Item Code Description  Soft
3.175-CM-2F-17-DLC 3.175mm x 3.175mm x 17mm  2F 5,350
3.175-CM-2F-22-DLC 3.175mm x 3.175mm x 22mm  2F 4,250
4-4-CM-2F-22-DLC 4mm x 4mm x 22mm  2F 6,600
6-6-CM-2F-22-DLC 6mm x 6mm x 22mm  2F 16,450
6-6-CM-2F-32-DLC 6mm x 6mm x 32mm  2F 10,500
8-8-CM-2F-32-DLC 8mm x 8mm x 32mm  2F 23,250
10-10-CM-2F-35-DLC 10mm x 10mm x 35mm  2F 42,150
10-10-CM-2F-45-DLC 10mm x 10mm x 45mm  2F 26,900
12-12-CM-2F-45-DLC 12mm x 12mm x 45mm  2F 53,600

Revolutions per minute 16,000RPM
100% width per cut slotting
Depth per cut Diameter x 1

3 Reviews Hide Reviews Show Reviews

  • 4
    2 Flute compression DLC carbide end mill

    Posted by John on 28th Feb 2024

    I cut heaps of 3mm and 4.75mm MDF. This is my goto end mill. Great clean cut and just so quiet.

  • 5
    2flute end mill

    Posted by Denis Brooks on 11th Oct 2023

    Great service, fast efficient and competive price. I do not shop with any other company.

  • 5
    Outstanding

    Posted by David on 16th Sep 2022

    Everything about this bit. Is great so far. About 8hrs into use and it is cutting clean, less noise.
